»zidCode«

Data Flow Without a Network

With the »zidCode«, your CNC machines are optimally protected against crashes even without a network because the tool data is transmitted error-free to the CNC machine via scanner and code.

This makes »zidCode« the ideal solution for production processes that work without a network. It's also perfect for CNC machines that are not prepared for networks.

»zidCode«

Data Flow Without a Network

With the »zidCode«, your CNC machines are optimally protected against crashes even without a network because the tool data is transmitted error-free to the CNC machine via scanner and code.

This makes »zidCode« the ideal solution for production processes that work without a network. It's also perfect for CNC machines that are not prepared for networks.

Integrates Seamlessly

»zidCode« is suitable for almost every production environment. For example, the solution transfers tool data directly to FANUC or HAAS controls via a network cable. So that you can also use the advantages of »zidCode« with older machines, data transfer is also very easy via serial interfaces such as RS232. Process optimization is only possible this efficiently with ZOLLER.

Integrates Seamlessly

»zidCode« is suitable for almost every production environment. For example, the solution transfers tool data directly to FANUC or HAAS controls via a network cable. So that you can also use the advantages of »zidCode« with older machines, data transfer is also very easy via serial interfaces such as RS232. Process optimization is only possible this efficiently with ZOLLER.



Installation

Barcode reader 1D/2D per CNC machine

»zidCode« unit per CNC machine for magnetic assembly

Software for »zidCode« on ZOLLER presetting and measuring machine
with image processing »pilot 3.0« or »pilot 2 mT«

USB stick (documentation, manual, training videos)

USB cable (connection »zidCode« unit with machine control unit)

Requirements

CNC control with USB connection, on which a simulated USB keyboard is recognized
(optional RS232 interface for data output)

ZOLLER presetting and measuring machine with image processing »pilot 4.0«,
»pilot 3.0« or »pilot 2 mT« from version 1.15.0.0,
or »pilot 1.0« from version 1.15.13.0

Thermal label printer

Order Efficiency
Now

You have the choice between »zidCode« without a network connection and the simple transfer of tool data from the QR code directly to the machine control system or »zidCode 4.0« for secure identification and networking of your tool data throughout the entire production process!
